7-inch multitouch panel with lot of visualisation power

(See SIGMATK at Machine Building North, 13 May 2026, on stand 4)

The black aluminium frame combined with a robust steel housing makes the panel the ideal choice for demanding industrial environments where mechanical robustness is required in addition to modern visualisation.

The operating panel comes with a quad-core EDGE3 technology processor with four cores (4x 1.6 GHz), 2 GB LPDDR4 RAM, and 8 GB microSD memory. This ensures that even complex applications can be displayed smoothly and with high performance.

The fanless HMI is equipped with a projected capacitive glass surface that enables precise and convenient operation using multi-finger gestures. Its 7-inch widescreen display with a resolution of 1024 x 600 pixels ensures clear, high-contrast visualisation of machine and process data. LASAL VISUDesigner (HTML5) is available for creating the visualisation, offering a wide range of ready-to-use operating elements and controls, enabling modern user interfaces to be implemented efficiently.

The ET 0711-02 offers OPC UA communication and a wide range of interfaces as standard: 2x Ethernet, 2x CAN, and 1x USB 2.0 Type A, USB 2.0 Type C, RS485, and RS232. This allows the panel to be integrated into a wide variety of automation architectures. A multi-status LED on the front reliably provides information about the current device status.

The web HMI is designed for installation in the control cabinet and has IP65 protection on the front.
